3.50 Medallions, Badges, Tank Emblems And Adhesive Strips

MEDALLIONS, BADGES, TANK EMBLEMS AND ADHESIVE
STRIPS                                                                                                                      3.50

REMOVE                                                          •    Parts cannot be repositioned after initial installation. Do not
                                                                     remove protective film from adhesive until ready to apply.
 CONSUMABLE                      PART NUMBER                    •    Do not bend emblem to fit contour of mounting surface.
3M GENERAL                                                      • Allow at least 24 hours after application before exposing the
PURPOSE                                                              area to vigorous washing, strong water spray or extreme
ADHESIVE                                                             weather.
REMOVER
                                                                •    The adhesive bond will increase to maximum strength after
1.    Mark location of emblem with masking tape.                     about 72 hours at normal room temperature.

2.    Remove emblem using fishing line or waxed dental floss.   1.    Test fit medallion.
                          NOTE
                                                                      a.    Check medallion against curve of mounting surface.
Wear protective gloves.
                                                                      b.    Match left and right sides of fuel tank or top cover,
3.    Remove remaining foam backing tape and adhesive from                  as applicable.
      mounting surface.
   Consumable: 3M GENERAL PURPOSE ADHESIVE                      2.    Remove protective film from back of medallion.
   REMOVER()                                                                             NOTE
                       NOTE
                                                                •    Protect adhesive from grease, oil, dust, dirt and
• Do not clean with denatured alcohol, mineral spirits or            fingerprints.
  other solvents. Damage to components may occur.
                                                                •    Once applied, do not shift medallion.
•    For maximum bond, surface must be clean and dry.
                                                                3.    Apply even pressure across entire surface. Hold in place
4.   Clean with a mixture of 50 percent isopropyl alcohol and         for 15 seconds.
     50 percent distilled water.
                                                                4.    Wait 20 minutes before touching medallion.
INSTALL

                      NOTE
• Apply in ambient temperatures between 70-100 °F
  (21-38 °C).

3-124                                                                                                                    94000784
