SPECIFICATIONS                                                                                                          5.2

DRIVE SPECIFICATIONS                                          Table 5-4. Balance Shaft and Crankcase Specifications
                                                              CASE BEARING BORE                  MM               IN
                Table 5-1. Sprocket Teeth                     Right Side Transmission Input     61.955          2.439
                                                              Left Side Transmission Input      51.963          2.046
        DRIVE              ITEM             NUMBER OF
                                                              Right Side Transmission Out-      51.963          2.046
                                              TEETH
                                                              put
Primary            Engine                       49
                                                              Left Side Transmission Output     61.955          2.439
                   Clutch                       89
Final              Transmission               19(SB)
                                                              TRANSMISSION AND CLUTCH
                   Rear wheel                 48 (SB)

           Table 5-2. Transmission Gear R atios                             Table 5-5. Clutch Specifications
GEAR                                   GEAR RATIO             TRANSMISSION                             DATA
First (low)                               2.857               Type                                   Wet 8-plate
Second                                     2.11               Clutch lever free play (after   1-2mm (Back off 2 full turns
Third                                     1.636               internal adjustment)                from finger tight)
Fourth                                    1.32
Fifth                                      1.11                      Table 5-6. Clutch Pack Plate Specifications
Sixth (high)                               0.97                        ITEM            NEW        SERVICE WEAR.
                                                                                 COMPONENTS           LIMITS
TRANSMISSION SPECIFICATIONS                                                      MM         IN     MM        IN
                                                              CLUTCH    Friction 2.80+1- 0.110+1- 2.62     0.103
                 Table 5-3. Transmission                      PLATE     plate     0.080   0.003
                                                              THICKNESS (fiber)
     TRANSMISSION                    SPECIFICATION
                                                                        Steel    2.00+1- 0.079+1-  NIA      NIA
Type                              Constant mesh, foot shift
                                                                        plate     0.120   0.005
Speeds                                   6 forward
                                                              MAXIMUM Friction     NIA     NIA     0.15    0.006
                                                              ALLOW-    plate
 Table 5-4. Balance Shaft and Crankcase Specifications
                                                              ABLE      (fiber)
CASE BEARING BORE                   MM               IN       WARPAGE Steel        NIA     NIA     0.15    0.006
Right Side Balance Shaft           41.965          1.652                plate
Left Side Balance Shaft            41.965          1.652
